PTFE tube/pipe is manufactured by the molding or ram extrusion method. It can withstand 1.6Mpa positive pressure and 77Kpa negative pressure; can be used normally within -60 ℃ ~ +260 ℃, with reliable and excellent corrosion resistance.
The PTFE pipe can be used to transport strong corrosive gas and liquid at high temperatures, which cannot be replaced by other pipes. It can be used in conductor insulation sheath, corrosive fluid medium pipeline, electrical insulation parts used under various high frequencies, etc.
Product specification
High and low-temperature resistance (-192 ℃-260 ℃),
Corrosion resistance (strong acid, strong alkali, aqua regia, etc.)
Weather resistance
High insulation
High lubrication
Non-adhesion
Non-toxic
| Type | Nominal diameter(mm) | Wall Thickness(mm) | Length(mm) |
| Extruded tube | 130-510 | 1.5-16 | As ordered |
| Molded tube | 30-525 | 7.5-95 | Max 300 |
